02:01 AM Deejay: moin
03:59 AM Tom_L: morning
04:02 AM Tom_L: 57°F & rain high 58°F
05:21 AM JT-Cave: morning
07:10 AM JT-Cave: rooster just crowed
07:16 AM JT-Cave: 50°F Partly Sunny High: 65°F
07:40 AM lcnc-relay: <desicated_coconut> Been setting up a CNC retrofit old machine with lcnc. I have https://cncu.co.za/EasyRoute-CNC-Router/Component%20Manuals/Fuling%20DZB200_DZB300%20Inverter%20User%20Manual.pdf and I have the freq command and on/off working but I cannot seem to control fwd/rev through the terminals. I can see that they are correctly switching high/low but the VFD only goes fwd. I have tried changing a few paramters.
07:40 AM lcnc-relay: <desicated_coconut>
07:56 AM jpa-: what pin on the VFD is the direction signal connected to?
07:58 AM Tom_L: P49 makes reference to K1 K2
07:58 AM jpa-: it seems if you set F2.01 = 1 and F2.02 = 2, you can use them as separate FWD/REV pins
07:59 AM jpa-: or you can set the "three wire control" setting to have enable and direction separately
07:59 AM Tom_L: F0-25 might have something to do with it
07:59 AM Tom_L: P.41
07:59 AM jpa-: and F2.07
08:00 AM Tom_L: i can barely read it :)
08:00 AM jpa-: anyway, if you list the parameter values and the pin connections, we can look it over :)
08:00 AM jpa-: seems like it can be configured in lot of ways
08:12 AM lcnc-relay: <travis_farmer (@_discord_731083529441640538:jauriarts.org)> i think that's the same VFD series i have for my CNC spindle...
08:14 AM lcnc-relay: <desicated_coconut> It certainly is a terrible PDF. I took k1/2 to mean just a connection to use with the key. I only have a spindle enable and a spindle direction. So I think 2 wire control 2 would be ideal.
08:14 AM lcnc-relay: <desicated_coconut> I have set them to FWD/REV now. It’s their default
08:15 AM lcnc-relay: <travis_farmer (@_discord_731083529441640538:jauriarts.org)> i have just fwd/rev with 0-10v frequency control, and it works great
08:15 AM lcnc-relay: <desicated_coconut> I will try changing F0.25 as that might do it
08:16 AM lcnc-relay: <desicated_coconut> I guess I could instead set my enable to be a forwardnpin rigjt
08:16 AM lcnc-relay: <desicated_coconut> That’s not a bad idea!
08:19 AM lcnc-relay: <desicated_coconut> I kind of forgot I could just remap pins as I felt like it. First time using lcnc
08:19 AM lcnc-relay: <travis_farmer (@_discord_731083529441640538:jauriarts.org)> lcnc is the best 🙂
08:20 AM lcnc-relay: <desicated_coconut> So far I’m liking it. I’m using a remora flexi-Hal board so it’s a bit different. Kind of wish I had something with mesa but it’s much cheaper this way
08:20 AM lcnc-relay: <desicated_coconut> Just want to understand the ui design part. I would like to modify it a bit
08:23 AM lcnc-relay: <travis_farmer (@_discord_731083529441640538:jauriarts.org)> lol, just now realized current version is 2.9 and devel is now 2.10... i really need to get out and update my system. been so long with the cold, and then the power outage for days...
08:24 AM lcnc-relay: <desicated_coconut> I’m always hesitant to update unless I have issues with things, too much change for problems
08:25 AM lcnc-relay: <travis_farmer (@_discord_731083529441640538:jauriarts.org)> i am just the opposite, i like to stay current. though it is a drag when they make breaking changes that i have to reconfigure again
09:26 AM lcnc-relay: <desicated_coconut> So I set it to have a fwd and rev output. I have them connected and confirm they work. However I cannot get it to switch between the two fwd/rev. It is quite starnge. I switched the order of the terminal so 1 is rev 2 is fwd and it was only going in reverse. I think its aprotection setting at this point. Will try f0.25
09:33 AM lcnc-relay: <desicated_coconut> Starting to think that terminal input is dead or just doesnt work
09:33 AM Tom_L: mmm rain gage shows 4.25" overnite
09:36 AM lcnc-relay: <desicated_coconut> Well that did it! Damn terminal didnt work so Ijust remapped the next one along!
09:37 AM lcnc-relay: <desicated_coconut> FWD and REV baby! (No idea why I would need that)
10:07 AM jpa-: one good use for REV i have heard is to clear out the long stringy chips that plastic sometimes leaves on endmills
10:09 AM lcnc-relay: <Lcvette> Merry Christmas Eve Everyone!
10:10 AM lcnc-relay: <Lcvette> 🎄🤶
10:12 AM lcnc-relay: <Lcvette> * 🎄 🎅
10:13 AM JT-Cave: 'Twas the night before Christmas, when all through the house not a creature was stirring, not even a chicken
10:14 AM JT-Cave: the chickens were all nestled all snug on their roosts while visions of crickets and worms danced in their heads
10:14 AM lcnc-relay: <Lcvette> https://matrix.org/_matrix/media/v1/download/matrix.org/jgmSgvNUOKRYqrTZXwcOmgDz
10:16 AM lcnc-relay: <Lcvette> https://matrix.org/_matrix/media/v1/download/matrix.org/fZnQAfZOxturGUlubMYhvSmZ
10:16 AM lcnc-relay: <Lcvette> 😄
10:25 AM lcnc-relay: <desicated_coconut> https://jauriarts.org/_matrix/media/v1/download/jauriarts.org/ICLmWNHFyfkHWtgGRVFQfllN
10:25 AM lcnc-relay: <desicated_coconut> https://jauriarts.org/_matrix/media/v1/download/jauriarts.org/EXzhQicQNRuVlsHTlMzVMNbu
10:25 AM lcnc-relay: <desicated_coconut> Any thoughts on why I get Z travel error when I do a X command?
10:28 AM jpa-: are you perhaps already outside Z limit?
10:28 AM jpa-: one way to get errors like that is if your home position is outside the normal travel limits
10:30 AM lcnc-relay: <desicated_coconut> Ohh interesting I can check that. I can manually jog ok though?
10:32 AM lcnc-relay: <desicated_coconut> Oh no I made sure to move it down into its travel a bit, so it should be well within. The Z axis is setup to home to 0 and min limit of -150
10:33 AM jpa-: also i'm not sure how it acts if you have first run a G1 that *would* put Z outside limits, and then run a G1 without Z parameter
10:33 AM jpa-: i think it may remember the Z because normally it would
10:34 AM jpa-: but hmm, i think for MDI it should move from current position in any case
10:40 AM lcnc-relay: <desicated_coconut> Anything I can try? Is jog and mdi different in terms of if a limit is active?
10:40 AM lcnc-relay: <Lcvette> if you are in a limit state there is no motion to avoid crashes, no axis should be movable while in this state
10:40 AM lcnc-relay: <Lcvette> fix your config
10:41 AM lcnc-relay: <Lcvette> add a small sushion between G53 XYZ0 and the soft limit
10:41 AM lcnc-relay: <Lcvette> * add a small cushion between G53 XYZ0 and the soft limit
10:41 AM lcnc-relay: <Lcvette> push the machine axis off the limit
10:42 AM lcnc-relay: <Lcvette> or temporarily invert the limit switch signal
10:43 AM lcnc-relay: <Lcvette> move off the limit then close and return that limit hal signal to the correct syntax
10:44 AM lcnc-relay: <Lcvette> you are also running an outdated version of probe basic that is no longer supported and has several bugs
10:44 AM lcnc-relay: <Lcvette> you should convert to linux debian 12 bookworm, linuxcnc 2.9 and the latest probe basic
10:44 AM lcnc-relay: <desicated_coconut> It’s the latest supported by the hardware I am using I believe.
10:45 AM lcnc-relay: <Lcvette> grab a spare ssd and try it
10:46 AM lcnc-relay: <Lcvette> probe basic running on 2.8 will run on 2.9
10:46 AM lcnc-relay: <desicated_coconut> I can try that then. Do you think that will fix this issue?
10:46 AM lcnc-relay: <Lcvette> no hardware issue there as the only thing would be the graphics support and its the same for both version
10:46 AM lcnc-relay: <Lcvette> nothing will fix a bad config except fixing the config
10:47 AM lcnc-relay: <desicated_coconut> It’s a pi so only need an sdcard to try it.
10:47 AM lcnc-relay: <Lcvette> if the simulation works but your configuration does not, its not PB its the config
10:47 AM lcnc-relay: <Lcvette> oh then no clue
10:47 AM lcnc-relay: <Lcvette> thats a diffeent animal
10:47 AM lcnc-relay: <Lcvette> ditch the pi and get a pc
10:47 AM lcnc-relay: <Lcvette> pb is not for pi and there are a bunch of issues
10:48 AM lcnc-relay: <desicated_coconut> That’s really unhelpful advice
10:48 AM lcnc-relay: <Lcvette> there is no advice for pi
10:48 AM lcnc-relay: <Lcvette> its not supported
10:48 AM Tom_L: :)
10:49 AM Tom_L: likely too slow to run all the gui properly
10:49 AM lcnc-relay: <Lcvette> meaning to make it work requires so amny patches and fixes that us trying to trouble shoot it would be near impossible
10:49 AM lcnc-relay: <Lcvette> if you want to run probe basic it is supposed to be run on a pc
10:50 AM lcnc-relay: <desicated_coconut> It runs fine, the issue is the error message you saw
10:50 AM lcnc-relay: <Lcvette> some of the other ui's using non VTK backplotter will work natively on pi
10:51 AM lcnc-relay: <Lcvette> PB for 2.8 has many bugs
10:52 AM lcnc-relay: <Lcvette> its may be one of them and fixing it would require setting up a dev pc and manually finding and fixing any code causing the bug
10:52 AM lcnc-relay: <Lcvette> we no longer have the ability to build for 2.8 linuxcnc
10:53 AM lcnc-relay: <Lcvette> so thgat is something you would need to do locally and specifically for you installation
10:53 AM lcnc-relay: <Lcvette> hence my reocmmendation to upgrade to 2.9
10:53 AM lcnc-relay: <Lcvette> but if your hardware handicapped.... what is the alternative
10:59 AM Tom_L: run a bookworm rpi4 deb with axis
11:02 AM lcnc-relay: <desicated_coconut> https://jauriarts.org/_matrix/media/v1/download/jauriarts.org/bRYmwSIzjHWxZIwlmZScrGpQ
11:02 AM lcnc-relay: <desicated_coconut> All good now. It was my misunderstanding of LCNC that was the issue
11:03 AM lcnc-relay: <desicated_coconut> Err ignore the other picture haha
11:09 AM jpa-: for future reference, what kind of misunderstanding? :)
11:14 AM lcnc-relay: <desicated_coconut> I think the code I generated with the conversational element had a move that went outside the motion limits. I didn’t think it looked ahead and line 57 kind of gave a clue there. My misunderstanding was when I did the MDI I think it still checks the loaded Gcode for issues as well. So the same error came up even though I had only an X move in it
11:24 AM lcnc-relay: <Lcvette> you will still run into bugs on that version notably the MDI is a known issue
11:24 AM lcnc-relay: <Lcvette> 2.9+
11:26 AM lcnc-relay: <Lcvette> you would need to check the forums to see if someone has found a solution for that.
11:30 AM lcnc-relay: <roguish> old Gene Heskett has been messing with RPi's quite a bit. try a letter to the email list....
11:35 AM lcnc-relay: <desicated_coconut> Cheers, I will see how things go and try and update if there is a route. It’s remora using the flexi-Hal, not sure if it’s in active development but even with the bugs in this version it’s already miles ahead of what I was using before and really great
11:36 AM lcnc-relay: <roguish> good luck.... keep us informed of your progress......
11:36 AM lcnc-relay: <roguish> start a topic on the forum. you'd be surprised how much help you could get...
